Large Diameter Flexible Flanged Rubber Hose

JIDONGDA Large Diameter Flexible Flanged Rubber Hose is mainly used for flexible connection and media transportation between large equipment, pump units, pipelines and mobile equipment.

The product adopts a rubber hose body combined with reinforcement structures and is equipped with flanges at both ends. It is suitable for conveying:

· Water

· Seawater

· Slurry

· Mineral slurry

· Sand and gravel

· Tailings

· Some industrial media

The main positioning of this product is flexible connection. Therefore, during selection, besides pressure and diameter, factors such as equipment vibration, pipeline displacement, installation deviation, bending space and hose length should also be considered.

Key Advantages

01 | Flexible Connection Capability

The rubber hose body provides certain bending and displacement adaptability, making it suitable for flexible connections near equipment interfaces.

02 | Large Flow Conveying

The large diameter structure can be used for large-volume media transportation. The specific diameter range shall be confirmed according to the actual product and project requirements.

03 | Flange Matching

Both ends can be equipped with carbon steel, stainless steel or other flanges, and can be matched according to common standards or customer drawings.

04 | Optional Suction and Discharge Structure

According to actual vacuum requirements, suitable reinforcement structures and spiral steel wire frameworks can be configured.

05 | Medium Adaptability

For media such as water, seawater, slurry, mineral slurry and sand, suitable inner rubber materials can be selected according to material requirements and wear conditions.

06 | Non-standard Customization

Customization is available for:

· Diameter

· Length

· Pressure

· Vacuum pressure

· Temperature

· Flange

· Rubber compound

· Color

Product Structure

The inner rubber layer directly contacts the conveying medium.

The reinforced fabric layer bears the pressure load.

When vacuum support is required, a spiral steel wire reinforcement structure can be configured.

The outer rubber layer provides aging resistance and environmental protection.

The end flanges are used for bolted connections between equipment and pipelines.

Why Choose Flexible Flanged Structure

When fixed pipelines experience pump unit vibration, equipment movement or installation errors, additional stress may occur at connection points.

Flexible rubber hoses can serve as flexible sections in pipelines, helping accommodate certain displacement and vibration.

The actual allowable bending radius, displacement range and installation method should be confirmed according to the specific structure.

Typical Installation Locations

Commonly used at:

· Pump suction or discharge ends

· Connections between equipment and main pipelines

· Mobile equipment connection points

· Industrial pipelines requiring frequent installation and disassembly

The flange dimensions must match the mating flange, sealing surface and bolt hole positions.

Technical Parameters

Application Industries

Mining:
Used for conveying mineral slurry, tailings and media containing particles.

Dredging:
Used for conveying slurry, sludge and sand.

Ports:
Used for large-flow liquid and material transportation.

Sand & Gravel:
Used for conveying water-sand mixtures and particle materials.

Construction Machinery:
Used for flexible connections between pumps, equipment and mobile pipelines.

Industrial Conveying:
Used for industrial water, slurry and other suitable conveying media.

Selection Points

When purchasing, it is recommended to provide the following information:

· Inner diameter

· Length

· Working pressure

· Working vacuum pressure

· Conveying medium

· Temperature

· Flow rate

· Bending/displacement requirements

· Flange standard

If used for vacuum suction applications, the vacuum pressure level should be clearly specified.

If conveying abrasive media such as sand or mineral slurry, the particle size and concentration should be provided.

Use and Maintenance

· Avoid exceeding the confirmed pressure, vacuum pressure and temperature range.

· Do not forcibly stretch or twist the hose during installation.

· Regularly inspect outer rubber cracks, bulges, abnormal wear and flange leakage.

· Stop using the hose and reconfirm operating conditions if structural damage or abnormal hose collapse occurs.

Product Customization / OEM & ODM

For non-standard specifications, products can be confirmed according to customer drawings, samples or technical parameters.

It is recommended to provide:

Inner Diameter / ID: ____

Length / Length: ____ m

Working Pressure / Working Pressure: ____ MPa

Working Vacuum / Vacuum: ____ kPa

Working Temperature / Temperature: ____ ℃

Conveying Medium / Medium: ____

Flange Standard / Flange Standard: ____

Flange Dimensions / Flange Dimensions: ____

Purchase Quantity / Quantity: ____

Destination Port / Destination: ____

FAQ

What are the main advantages of this hose?

The main advantages are the combination of large diameter conveying and flexible connection capability, making it suitable for applications involving equipment vibration, pipeline displacement and installation deviation.

Can the flange be manufactured according to drawings?

Yes. Technical confirmation can be carried out according to the flange standard, dimensions or drawings provided by customers.

Can it be used for mineral slurry?

Yes. Suitable inner rubber materials and reinforcement structures can be selected according to mineral slurry concentration, particle size, flow rate, pressure and temperature.

What is the MOQ?

MOQ is confirmed according to specification, length, structure and customization requirements.

Standard products can support small-batch purchasing depending on order conditions.

What is the delivery time?

Standard products can usually be arranged within approximately 7–20 working days.

Customized products and special specifications shall be confirmed according to order requirements.
